Technical parameters ：
| Dimension of sliding table | 2800×375mm |
| Max cutting length | 2800mm |
| Max lengthways cutting | 1250mm |
| Cutter blade specification | φ300（φ250-φ435mm） |
| Max.working height | 80mm |
| Speed of main saw spindle | φ40 |
| Speed of main saw spindle | 4000/6000rpm |
| Main spindle diameter | 30mm |
| Tilting saw bladle | 90° |
| Main motor power | 4kw或5.5KW |
| Scriber specification | ∮120mm |
| Non-loadspeed | 8000r/min |
| Scoring spindle diameter | 20mm |
| Scoring motor power | 0.75kw（1.1kw） |
| Net weight | 600kg |
| Net weight | 700kg |
| Overall dimensions | 2800×2830×985mm |
